Customized Solutions with Leading Brands

Industry-standard testing machines for electronic circuit boards achieving high productivity and contact accuracy simultaneously. The pass rate and throughput greatly affect the productivity in the electrical testing process of circuit substrates. While improving both of these has proven difficult using the existing fixture method or flying method, Yamaha's Flying Fixture™ method has solved this.

A wide range of sheet materials from thin to thick ones are supported. With an electric punching head, high-speed, high-accuracy punching is realized. Our proprietary electric punching head realizes punching at high speed up to 0.08 seconds/hole. In addition to high-precision (±20 μm) machining based on image alignment, also supported is NC machining for exposure fiducial marks.

Used for film materials for such work sheets as FPCs and touch panels. Metal die punching and half-cutting are also supported. This model is an irregular hole puncher for film materials in response to various types of product machining requirements, such as FPC connector section trimming and touch panel outline machining. It is characterized by high-accuracy (±20 μm) punching based on image alignment. Metal die punching and half-cutting using a blade are also possible.

Widely used across multiple industries including FPCB, PCB, ceramic substrates, LCD BLU, PDP, and screen printing. Types: Roller & Tape Type Features: Powerful double-sided simultaneous cleaning & Easy maintenance & High safety.
